6th Gen Intel Xeon/Core i7/i5/i3/Celeron processorEthernet Intel® i211AT MINIPCIE 4Gx1USB3.0x2,USB2.0x8
Processor
SOM-5897,SOM-6897
M.2 2230
WIFI X1
M.2 2280
SATA X3
M.2 3052
5G X1
Display
HDMI ,EDP
I/O
USB3.0X4,USB2.0X8
Ethernet
Intel® i211AT
MINI-PCIE
4G X1
Power Requirement
+12V, AT/ATX
Board Size
203x146mm(8”x5.75”)
Operating Temp.
A ：0℃～+60℃ B：-10℃～+70℃
Storage Temp.
-40°F ~ 176°F (-40°C ~ 80°C)
MTBF (Hours)
60,000
