规格参数

Processor	RM926EJ-S™ ARM ®  Thumb ®  Processor running at up to 400 MHz @ 1.0V +/- 10%
Memory	Onboard 128MB DDR2 memory
SSD	Onboard 256MB nandflash memory with chip selection control switch
Display	LCD Controller with overlay, alpha-blending, rotation, scaling and color conversion
I/O	AMI 4M Flash ROM
Display	Intel® Graphics Media Accelerator 4500MHD1xVGA ,  18/24-bit dual channel LVDS  up to 2560x1600
I/O	One 10/100 Mbps Ethernet MAC Controller Two High Speed Memory Card Hosts  Two CAN Controllers Two Master/Slave Serial Peripheral Interface Two 3-channel 32-bit Timer/Counters One Synchronous Serial Controller One 4-channel 16-bit PWM Controller Three Two-wire Interfaces Three USARTs, two UARTs, one DBGU One 12-channel 10-bit Touch-Screen Analog-to-Digital Converter Soft Modem Write Protected Registers USB Device High Speed, USB Host High Speed and USB Host Full Speed with dedicated On-Chip Four 32-bit Parallel Input/Output Controllers 105 Programmable I/O Lines Multiplexed with up to Three  Peripheral I/Os Input Change Interrupt Capability on Each I/O Line, optional Schmitt trigger input Individually Programmable Open-drain, Pull-up and     pull-down resistor, Synchronous Output
Board Size	67.5x35mm,DDR2 SDIOIMM200pin interface
